CNC Side Boring Machine For Panel Furniture and Handle-Free Grooving
CK-360
The SAMDY CK-360 is a CNC side drilling and boring machine designed for panel furniture production. It is used to process horizontal side holes, blind holes, dowel holes, hardware mounting holes, concealed connector grooves, and handle-free grooves on cabinet and furniture panels.
The machine combines CNC positioning, multiple drilling spindles, automatic workpiece positioning, and pneumatic clamping to provide efficient and consistent side-hole processing. It is suitable for cabinets, wardrobes, kitchen furniture, office furniture, wooden doors, and customized panel furniture production.
Technical Specifications
| Specification | Details |
|---|---|
| Model | CK-360 |
| Machine Type | CNC Side Drilling and Boring Machine |
| Maximum Working Thickness | 60 mm |
| Maximum Working Length | 2700 mm |
| Maximum Working Width | 140 mm |
| Working Table Size | 500 × 2800 mm |
| Working Speed | 60 m/min |
| Vertical Spindles | 3.5 kW × 2 |
| Horizontal Spindle | 2.2 kW × 1 |
| Total Power | 12.25 kW |
| Control System | CNC Control System |
| Clamping System | 8 Groups of Movable Pneumatic Clamping Cylinders |
| Machine Dimensions | 3600 × 1450 × 1300 mm |
| Machine Weight | 1200 kg |
| Main Applications | Side Holes, Dowel Holes, Hardware Mounting Holes, Connector Holes, Blind Holes and Handle-Free Grooves |
function
Hardware Mounting Holes
The machine can process side holes for cabinet hardware, hinges, drawer slides, handles, cam locks, dowels, Minifix connectors and other furniture fittings.
Dowel and Connector Holes
It can drill side holes for dowels and 3-in-1 or 2-in-1 furniture connectors used in cabinet and panel furniture assembly.
Handle-Free Grooves
The CK-360 can machine handle-free grooves for modern handleless cabinet and wardrobe designs.
Blind Holes and Grooves
The CNC system can process blind holes and grooves on panel edges according to the programmed processing requirements.
share:
Description
CNC Side Boring Machine Processing :
• Side holes, dowel holes, and blind holes for 3-in-1/2-in-1 connectors;
• Grooves and holes for concealed connectors (Lamine,Wood-based etc);
• Handle-free grooves, hinge holes, and mortise and tenon grooves ;
• Grooving and venting holes on the sides of boards, etc.
The 3 heads CNC side drilling machine is a core piece of equipment in the automated production of panel furniture. It has advantages of high efficiency, precision, multi-functionality, and ease of operation, it completely replaces traditional manual drilling machine.Works best when used in conjunction with CNC cutting machine.
CNC Side Boring Machine vs. CNC Six-Side Drilling Machine
CNC side drilling machine is mainly designed for horizontal drilling and grooving on the sides or edges of panels. It is suitable for hardware mounting holes, dowel holes, connector holes and handle-free grooves.
CNC six-side drilling machine can process holes and grooves on the top, bottom, front, rear and both side surfaces of a panel. It is generally used when a wider range of panel surfaces needs to be processed automatically.
For furniture factories that mainly need side-hole and edge-groove processing, a dedicated CNC side drilling machine can be integrated with cutting and other panel-processing equipment as part of the production workflow.
Use Scenarios
Cabinet Manufacturing
For side holes, connector holes, dowel holes and handle-free grooves in kitchen cabinets and storage cabinets.
Wardrobe Manufacturing
Suitable for drilling and grooving cabinet side panels and wardrobe components.
Custom Furniture Production
Suitable for customized furniture with different hole positions and non-standard panel designs.
Office Furniture
For desks, cabinets, shelves and other panel furniture components.
Wooden Door Processing
Can be used for selected side drilling and mounting-hole applications on wooden door components.
Key Features
Three-Spindle Configuration
The CK-360 is equipped with three processing spindles for different side drilling and grooving operations.
CNC Positioning
CNC-controlled positioning helps maintain consistent hole locations during repeated production.
Pneumatic Clamping
Multiple movable pressing cylinders hold the panel securely during machining to reduce movement and vibration.
High-Speed Processing
With a listed working speed of up to 60 m/min, the machine is designed for efficient side-hole and groove processing.
Touchscreen Control
The touchscreen control interface allows operators to manage machine settings and processing operations conveniently.
Precision Screw Drive
The screw-drive system is designed to provide stable movement and consistent positioning during machining.
Laser scanning
Laser scanning allows for rapid order switching and flexible production
FAQ
What is a CNC side drilling machine?
CNC side boring machine is designed to automatically drill horizontal holes and grooves on the edges or sides of furniture panels. It is commonly used for cabinet, wardrobe and panel furniture production.If you need to finish 6 sides drilling at same time,CNC 6 sides drilling machine is a good option.
What can the CK-360 CNC side boring machine process?
The CK-360 can process side holes, blind holes, dowel holes, hardware mounting holes, concealed connector grooves, handle-free grooves and other side-processing applications.
What materials can the CNC side drilling machine process?
The machine is primarily designed for panel furniture materials such as MDF, particleboard, plywood and other suitable wood-based panels,honeycomb aluminum panel also can be proceed.
Can it process handle-free cabinet grooves?
Yes. The CK-360 is designed for handle-free grooves and other side-grooving applications used in modern cabinet and wardrobe production.
Can it drill holes for Minifix and dowel connectors?
Yes. The machine can be used for side holes and connector holes for common panel-furniture assembly systems, including dowels and 3-in-1/2-in-1 connectors.
Drilling Spindle
3 spindles (2 horizontal heads +1 vertical heads)
3 spindles to process a variety of products.（3.5kw*2+2.2kw *1）
Automatic Tool Setting
Vertical
Automatic positioning to ensure processing accuracy.
Position Cylinder
Movable pressing cylinder
8 groups of movable pressing cylinder to make sure pressing panel well during processing.
Precision Screw
High precision and stable
Screw drive ensures the accuracy and stability of machine processing.
Control System
Touch screen
Touch screen control system, easy to operate.
Finished Products
Multiple functions
Can process a variety of products to meet all your cabinet processing requirements.
