SV-368
KTD style edge banding machine SV- 368 is a basic model with double trimming-fine trimming and rough trimming.Edge banding machine is to apply a strip of edge banding material (such as PVC, ABS, wood veneer, or melamine) to the exposed edges of panel materials like particleboard, MDF, or plywood.
SV-368 is economy and basic machine without premilling and corner rounding function,if you use panel saw for cutting raw boards,SV-368J edge banding machine is the best choice for you.
Basic configuration
| Item | SV-368 Standard Parameter |
| Min Workpiece Length | ≥200mm |
| Min Workpiece Width | ≥60mm |
| Processing Board Thickness | 10–60mm |
| Supported Edge Tape Thickness | 0.3–3mm PVC/ABS/Melamine/Veneer |
| Working Air Pressure | 0.7Mpa |
| Total Installed Power | 9.5 KW |
| Overall Machine Dimension | 4300*1000*1600mm |
| Rough Trimming Motor | 0.75KW*2 Flat cutter motors |
| Fine Trimming Motor | 0.75KW*2 R-round cutter motors |
| Buffing Motor | Dual 0.37KW buffing motors |
| Optional Upgrade | PUR Gluing / Pneumatic Adjustable Cutter |
Function
Buffing-Spray cleaning-Scraping-Fine trimming-Rough trimming- End cutting- Gluing (Electric lifting)
share:
Description
KTD style edge banding machine SV-368 includes buffing, spray cleaning, scraping, double trimming,end cutting, and gluing with electric lifting. Optional PUR gluing and pneumatic adjusting cutter tooling add flexibility for different applications. Rough trimming and fine trimming, ensuring the upper and lower edges of boards are smooth.. A heavy-duty body ensures durability, while pressing rollers with flat knives provide uniform pressure, making the tape adhere firmly.
Common production bottlenecks which global medium & small cabinet, wardrobe furniture factories are facing:
1.Uneven edge finish by manual edge banding, white edge marks after trimming, manual polishing rework takes 12–20 mins
2.Unstable electrical control system
3.precision problem after 1-2 years.
Our edge banding machine sv-368 has double rough and fine trimming eliminates white edge residue, rework rate reduced by 76%,buffing function can finish polish at same time.We adopt Taiwan Shilin control system + Schneider contactors, MTBF reach 720 hours (industry average only 420h).And SV-368 machine weight is over 1000kgs,fine trimming and rough trimming supports width are 8mm,heavy duty type ensure SV-368 keep high precision after using more than 5 years.
FAQ about SV-368
Q1: What kind of factories is SV-368 suitable for?
A: Ideal for medium & small cabinet/wardrobe factories with daily output 100–400 sheets,SV-368 is the most cost-effective double trimming model, no need to buy high-end large automatic edge bander.
Q2: Can SV-368 support PUR glue edge banding?
A: PUR gluing system is an optional upgrade module. Standard machine adopts EVA hot melt glue for mass cabinet production.
Q3: What’s the minimum workpiece size the machine can process?
A: Min length ≥200mm, min width ≥60mm. Most similar edge banders only support ≥250mm length & ≥80mm width, SV-368 solves small drawer panel processing pain point.
Q4: How long is the machine’s warranty & after-sales service?
A: Whole machine 12-month warranty.
Q5: What’s the total power consumption per day?
A: Total power 9.5KW, continuous operation power consumption around 7–8 degrees per hour.
Q7: Can this machine connect with CNC wood router & six-side drilling machine to form full production line?
A: Fully compatible. We provide matching production line layout plan, SV-368 stably cooperate with our CNC cutting machine, six-side drill to complete full automatic panel furniture production flow.
Use Scenarios
• Kitchen cabinet & cupboard mass production
• Wardrobe, walk-in closet customized furniture
• Balcony storage cabinet, shoe cabinet, vanity cabinet
• Office desk, filing cabinet, commercial office furniture
• Custom hotel apartment furniture, simple solid wood composite furniture
Machine advantage
1. Control System: Taiwan Shilin PLC, touch screen, inverter + France Schneider contactors
2. Gluing System: 2-layer heat dissipation EVA glue tank, optional PUR glue unit, electric lifting pressure beam
3. Pressing Unit: 3 metal pressing rollers + 1 flexible rubber roller with scraper
4. Trimming Group: Flat rough trimming + R-type fine trimming, dual independent motor for each station
5. Finishing Group: Flexible scraper, synchronous end cutting, spray cleaning, dual buffing motors
6. Body: Heavy-duty integral thick steel frame, anti-vibration welding structure
Touch screen
Taiwan China Shilin Brand
Taiwan China Shilin Brand
PLC and Inverter
Taiwan China Shilin Brand
Good quality ensure machine working stable and provide good after sale service.
Famous Brand Contactor
French Schneider brand
Reliability & Durability & Safety.
Gluing
2- layer structure
It is easy to heat dissipation, good stability, Good structure for EVA hot melt glue.
Press Rollers With Scraper
3 pressing roller
Segmented pressure distribution: metal rollers bear heavy pressure for thick tape, rubber roller fits thin soft PVC/veneer.
Rough Trimming And Fine Trimming
Flat cutter rough trimming and "R" cutter fine trimming
R round arc cutter smooth the upper & lower board edges, reserve micro margin for scraping process, completely remove white edge marks; freely switch parameters for 0.3–3mm tape without shutdown debugging.
Using 0.75KW*2 motors for rough trimming.
Using 0.75kw*2 motors for fine trimming.
Buffing
Dual motor buffing
0.37kw*2 motor and double polishing wheel symmetrical buffing, restore furniture surface gloss, eliminate trimming tool marks, one-step finished without secondary manual polishing
Flat Scraper
Flexible scraper
Elastic scraper automatically fits board surface, wipe residual glue lines without scratching veneer or melamine surface, cut manual glue cleaning work by 80%.
Electric Lifting
Electric lifting pressing beam
Simple operation, save time for you.
Professional exporting
Full container loading
Professional loading container experience
